57320010020

Home
/
Products
/
57320010020

57320010020

Specification

MATERIAL AND FINISH

1.INSULATOR:LCP,RATED UL94V-0,COLOR:BLACK 2.CONTACTS:PHOSPHOR BRONZE SN 160u"AT SOLDER TAIL SELECTIVED AU ON CONTACT AREA PLATING 3.GROUND:PHOSPHOR BRONZE,SN 160u" 4.SHELL:STAINLESS

ELECTRICAL CHARACTERISTIC

1.OPERATING VOLTAGE:3.3V 2.CURRENT RATING:0.5A 3.INSULATION RESISTANCE:1000MΩMIN.AT250V DC 4.DIELECTRIC WITHSTANDING VOLTAGE:500V AC/1MINUTE 5.CONTACT RESISTANCE:100mΩMAX 6.MATING CYCLE:10000CYCLES,SPRING IS NOT BREAKING

ENVIRONMENT

1.OPERATING TEMPERATURE:-25°C~90°C

PACKG STYLE

1.TAPE REEL 2.TRAY
