53101010010
53101010010
Specification
MATERIAL AND FINISH
1.INSULATOR:LCP UL94-VO BK
2.TERMINAL:C5191,1u〞AU OVER 50u〞~80u〞NI
3.SHELL:SUS201,SN PLATED
ELECTRICAL CHARACTERISTIC
1.CURRENT RATING:1.0A
2.VOLTAGE RATING:30V
3.DURABILITY:5000CYCLES MIN
4.WITHSTANDING VOLTAGE:100V AC MIN
5.CONTACT RESISTANCE:30ΩMAX.INITIAL;40mΩMAX.
AFTER 3000 CYCLES
6.INSULATOR RESISTANCE:100mΩMIN
MECHANICAL CHARACTERISTIC
1.ENGAGEMENT FORCE:35N MAX
2.DISENGAGEMENT FORCE:10N MIN.INITIAL 8-20N AFTER
5000 CYCLES
ENVIRONMENTAL
1.OPERATING TEMPERATURE RANGE:-30°C TO+80°C
2.PACKING OPTION:TAPE REEL
