5132202XXX0
5132202XXX0
Specification
MATERIAL AND FINISH
1.INSULATOR:PA6T,UL94V-0,BLACK
2.CONTACT:PHOSPHOR BRONZE
PLATING:SN,GOLD PLATED
STANDARD:GOLD FLASH ALL OVER
ELECTRICAL CHARACTERISTIC
1.CURRENT RATING:2 A
2.CONTACT RESISTANCE:20 mΩ MAX
3.INSULATOR RESISTANCE:5000 MΩ MIN
4.DIELECTRIC WITHSTANDING:500 V AC
ENVIRONMENT
1.OPERATING TEMPERATURE:-40°C~+105°C
2.MAX PROCESSING TEMP:230°C FOR 60 SECONDS
260°C FOR 10 SECONDS
