5023701XXXX
5023701XXXX
Specification
MATERIAL AND FINISH
1.INSULATOR:PBT,GLASS FILL REINFORCED UL94V-0,BLACK
2.CONTACTS:BRASS(STANDARD)
3.SHELL:STELL,SN OR NI PLATED
4.RIVET,BOARDLOCK:COPPER ALLOY
ELECTRICAL CHARACTERISTIC
1.OPERATION VOLTAGE:250 VAC MAX
2.CURRENT RATING:3 A MAX
3.CONTACY RESISTANCE:15 mΩ MAX
4.INSULATION RESISTANCE:3000 MΩ MIN.@500 VDC
5.DIELECTRIC WITHSTANDING VOLTAGE:1000 VAC/MINUTE
ENVIRONMENT
1.OPERATING TEMPERATURE RANGE:-55°C TO+105°C
