50245010010
50245010010
Specification
MATERIAL AND FINISH
1.INSULATOR:THERMAL PLASTIC UL94V-0,BLACK
2.CONTACTS:COPPER ALLOY
PLATING:UNDERPLATE:50u〞NI
CONTACT AREA:1〞~30u〞AU
SOLDER TAILS AREA:100u〞SN
3.SHELL:STEEL,SN OR NI PLATED
4.RIVET,BOARDLOCK:COPPER ALLOY
ELECTRICAL CHARACTERISTIC
1.OPERATION VOLTAGE:250VAC MAX
2.CURRENT RATING:2.5A
3.CONTACT RESISTANCE:15mΩMAX
4.INSULATION RESISTANCE:3000MΩMIN.@500VDC
5.DIELECTRIC WITHSTANDING VOLTAGE:1000VAC/MINUTE
ENVIRONMENT
1.OPERATING TEMPERATURE RANGE:-55°C TO+105°C
