MATERIAL AND FINISH
1.INSULATOR:THERMAL PLASTIC UL94V-0,GLAY
2.CONTACT:COPPER ALLOY
PLATING:UNDERPLATE:50~100u”NI
CONTACT AREA:1~30u”SELECTIVE GOLD
SOLDER TAILS AREA:100~200u”SN(LEAD FREE)
3.SHELL:STEEL
4.RIVET,BOARDLOCK:COPPER ALLOY
ELECTRICAL CHARACTERISTIC
1.OPERATION VOLTAGE:250 VAC MAX
2.CURRENT RATING:TEMP(°C) 20 70 100
CURRENT 2.0A 1.6A 1.0A
3.CONTACT RESISTANCE:20mΩ MAX
4.INSULATION RESISTANCE:1000 MΩ MIN.@500 VDC
5.DIELECTRIC WITHSTANDING VOLTAGE:1000 VAC/MINUTE
ENVIRONMENT
1.OPERATING TEMPERATURE RANGE:-55°C TO+125°C
